Grinding is metal running on metal with nothing left in between. On a residential door the answer is worn roller bearings far more often than anything else, which means the cheapest possible outcome is also the most likely one. Ten rollers that have stopped rolling and started sliding produce exactly the sound people describe when they call about a grinding door.
Most grinding is ten rollers that stopped rolling
Close the door, then take hold of each roller in turn and try to spin it with your fingers. A healthy one turns freely. One that will not move, or that rocks on its stem, is finished. Builder-grade steel rollers use an exposed bearing race that fills with dust and dries out, and when the race collapses the roller drags along the track instead of running on it. A full set of ten sealed nylon rollers is an estimated $125 to $265 and drops the noise floor of the whole door. The eight you can reach are safe to inspect. The bottom pair are not, because they sit in the bottom brackets that anchor the lift cables under tension.
A three-bay door in Westhaven is not old, it is worn
The 2010s carriage-house facades through Westhaven, Berry Farms and Ladd Park fail on cycle count rather than age. On a three-bay elevation where one door is the family's front door, that leaf can see six or eight cycles a day while its neighbors see two a week, so the middle door on a six-year-old house is often twice as worn as the ones either side of it. When somebody says the door cannot need parts because the house is new, that is the number worth explaining. Rollers, hinges and springs count movements, not birthdays.
Where the noise sits tells you what it is
Do the listening with the opener disconnected, since the motor covers up everything useful. Pull the release, raise the door slowly by hand, and pause every foot or so. A noise that comes back at the same point on every pass is a roller. A low rumble that follows how fast you are moving, and that stays up at head height instead of traveling with the door, is the bearings on the shaft. Scraping confined to the radius where the track bends from vertical to horizontal is either alignment or a stem worn oval. A door that is silent by hand is not the part that needs work.
Bearings on the shaft, and why they are not a Saturday job
The torsion shaft turns in an end bearing plate at each side of the opening and usually a center bearing above the middle of the door. They are plain bushings and they run dry with age, at which point the grind is continuous and comes from above the door rather than from the track. Reaching them means taking the springs down, because the shaft, the drums and the springs come apart as one assembly. That is professional work every time, and the reason is stored energy rather than skill.
When the grind is the motor rather than the door
Quiet by hand and rough under power puts the fault in the drive. Chain that has gone slack slaps the rail. A sprocket with worn teeth chews at the chain. A nylon main gear that is shearing sounds worse than either, and the giveaway is a scatter of white dust under the motor when the cover comes off. Opener repair covering a gear and sprocket kit is an estimated $129 to $315, a replacement logic board an estimated $165 to $340, and a whole new unit supplied and fitted an estimated $385 to $695. Guide bands rather than quotes.
Grease belongs on four things
- Roller stems and hinge pins, a light lithium or silicone garage door spray, wiped back so it does not run.
- The torsion spring coils, along the length, which quiets them and slows corrosion at the same time.
- The end bearings and the center bearing, where the shaft enters them.
- The opener rail, a thin smear on a chain drive and nothing at all on a belt.
Two things get nothing. The inside of the tracks, because a track is a guide rather than a bearing surface, and grease there collects grit and turns into lapping paste. And penetrating spray sold as a rust breaker, which is a solvent and strips out what little grease is left. Brush the tracks out instead, which under mature trees is a twice-a-year job rather than an annual one.
An annual tune-up at an estimated $89 to $165 per door covers the lubrication above plus balance, hardware torque and the reversing test. Booking it in February, ahead of the March to May storm season, catches the parts a wet spring would otherwise finish off.
